Product Description Of AD5274BCPZ-100

AD5274BCPZ-100 is single-channel, 1024-/256-position digital rheostats that combine industry leading variable resistor performance with nonvolatile memory (NVM) in a compact package.

Product Attributes Of AD5274BCPZ-100

Feature Of AD5274BCPZ-100

• Single-channel, 1024-/256-position resolution

• 20 kΩ, 50 kΩ, 100 kΩ nominal resistance

• Maximum ±1% nominal resistor tolerance error

• 50-times programmable (50-TP) wiper memory

• Rheostat mode temperature coefficient: 5 ppm/°C

• 2.7 V to 5.5 V single-supply operation

• ±2.5 V to ±2.75 V dual-supply operation for ac or bipolar operations

• I2C-compatible interface

• Wiper setting readback

• Power on refreshed from 50-TP memory

• Thin LFCSP 10-lead, 3 mm × 3 mm × 0.8 mm package

• Compact MSOP, 10-lead 3 mm × 4.9 mm × 1.1 mm package

Applications Of AD5274BCPZ-100

• Mechanical rheostat replacements

• Op-amp: variable gain control

• Instrumentation: gain, offset adjustment

• Programmable voltage to current conversions

• Programmable filters, delays, time constants

• Programmable power supply

• Sensor calibration
