Product Description Of ADG1334BRSZ
ADG1334BRSZ is a monolithic CMOS device comprising of four independently selectable SPDT switches designed on a CMOS process.
When the switches are on, each switch conducts equally well in both directions and has an input signal range that extends to the power supplies. In the off condition, signal levels up to the supplies are blocked. All switches exhibit break-before-make switching action for use in multiplexer applications. Inherent in the design is the low charge injection for minimum transients when switching the digital inputs.
Fast switching speed coupled with high signal bandwidth makes the part suitable for video signal switching. CMOS construction ensures ultralow power dissipation, making the part ideally suited for portable and battery-powered instruments.
Specifications Of ADG1334BRSZ
4 Channel
4 x SPDT
200 Ohms
5 V
16.5 V
+/- 5 V
+/- 16.5 V
130 ns
85 ns
- 40 C
+ 105 C
Height:
1.75 mm
Length:
7.2 mm
Pd - Power Dissipation:
6.02 mW
Supply Current - Max:
400 uA
Supply Type:
Single Supply, Dual Supply
Switch Continuous Current:
24 mA
Width:
5.3 mm
Unit Weight:
453.600 mg
Features Of ADG1334BRSZ
33 V Supply Range
130 Ω on Resistance
Fully Specified at ±15 V/+12 V
3 V Logic Compatible Inputs
Rail-to-rail Operation
Break-before-make Switching Action
20-lead SSOP Package
Higlights Of ADG1334BRSZ
3 V logic compatible digital input VIH = 2.0 V, VIL = 0.8 V. 2.
No VL logic power supply required.
Low power consumption.
20-lead SSOP
Applications Of ADG1334BRSZ
Audio and Video Routing
Battery-powered Systems
Signal Routing
