BCM56880B0KFSBG High Capacity StrataXGS Trident 4 Ethernet Switch Chip

 BCM56880B0KFSBG High-Capacity StrataXGS Trident4 Ethernet Switch Chip

Product Description Of BCM56880B0KFSBG
BCM56880B0KFSBG is Ethernet switches designed to address performance, capacity, and service requirements for next-generation data center and cloud computing environments as well as high-bandwidth enterprise and mobile network applications. The BCM56880B0KFSBG's Trident 4 architecture delivers complete, user-programmable forwarding and instrumentation capabilities at a very high port density, while maintaining minimum power, latency and board footprint.

Product Features Of BCM56880B0KFSBG

• Enables the next major advancement in enterprise data center and campus networks, supporting up to 128x100GbE or 32x400GbE switching and routing with a compiler-programmable architecture

• Provides the flexibility to implement both standard Ethernet switch/routing and advanced network functionality such as DDoS protection, application load balancing, and large-scale NAT

• An extremely rich, enterprise-grade feature set with a high degree of feature concurrency

• Industry-leading packet buffer and database sizes

• Extensive programmable in-band telemetry including support for IFA 2.0 (In-band Flow Analyzer version 2)

• Four GHz-class processors on chip enabling powerful out-of-band (streaming) telemetry and a variety of Broadcom-provided embedded applications

• A wide variety of load balancing and congestion management features including Dynamic Load Balancing, Dynamic Group Multipathing, Resilient Hashing, Latency-Based ECN marking, and Elephant Flow detection and re-prioritization

• Architecture scalability for bandwidth requirements throughout the enterprise network: SKUs available at 2.0T to 12.8T, all supported with the same NOS and hardware code base

• Broadview™ Gen 4 integrated network instrumentation feature set and software suite, providing full visibility to network operators into packet flow behavior, traffic management state, and switch internal performance

• Robust connectivity using up to 256 instances of the industry’s best performing, longest-reach 50G PAM-4 integrated SerDes core, enabling a wide variety of optical and direct attached copper (DAC) links

• Industry’s first switch chip implemented all in 7nm process technology


Applications Of BCM56880B0KFSBG

• Datacenter programmable ToR (Top-of-Rack)

• Datacenter leaf/spine

• Core aggregation

• Switch blade in a server chassis

• Line card and fabric in a switch chassis

• Border/Data Center Interconnect (DCI)

• Gateway

• DDoS protection

• Application Load Balancing

• Large Scale NAT
