CH7517A Integrated Circuit Chip Low-Power DisplayPort To VGA Converter QFN-40

CH7517A Integrated Circuit Chip Low-Power DisplayPort To VGA Converter QFN-40

Product Description Of CH7517A

CH7517A is a low-cost, low-power semiconductor device that translates the DisplayPort signal to the VGA. This innovative DisplayPort receiver with an integrated VGA encoder is specially designed to target the notebook/ultrabook, tablet device and PC market segments. Through the CH7517A's advanced decoding / encoding algorithm, the input DisplayPort high-speed serialized multimedia data can be seamlessly converted to analog RGB video output.

Features Of CH7517A

• Compliant with DisplayPort specification version 1.2 and Embedded DisplayPort (eDP) specification version 1.3.

• Support 2 Main Link Lanes at either 1.62Gb/s or 2.7Gb/s link rate

• VGA output is compliant with VESA VSIS v1r2 specification

• Embedded MCU to handle the control logic

• Support device boot up by automatically loading firmware from on-chip flash Boot ROM

• Integrated EDID Buffer, and MCCS bypass supported

• Supports Enhanced Framing Mode

• Fast and full Link Training for embedded DisplayPort system

• Support eDP Authentication: Alternative Scramble Seed Reset and Alternative Framing

• 2 work modes: connect 27MHz crystal, inject 27MHz clock

• DAC connection detection supported

• DP input detection supported

• Support Auto Power Saving mode and low stand-by current

• Support Spread Spectrum Clocking (de-spreading) for EMI reduction

• DP AUX channel and IIC slave interface are available for firmware update and debug

• Low power architecture

• 3.3V/1.05V power supply supported for motherboard solution design

• RoHS compliant and Halogen free package

• Offered in 40-Pin QFN package (5 x 5 mm)

Applications Of CH7517A

• Notebook/Ultrabook

• Tablet Device

• Handheld/Portable Device

• PC
