ISO7520CDWR Integrated Circuit Chip Low-Power Dual-Channel Digital Isolators SOIC-16

ISO7520CDWR Integrated Circuit Chip Low-Power Dual-Channel Digital Isolators SOIC-16

Product Description Of ISO7520CDWR

ISO7520CDWR provide galvanic isolation of up to 4243 VRMS for 1 minute per UL and 6000 VPK per VDE. These devices are also certified to 5000 VRMS reinforced insulation per end equipment standards IEC 60950-1, IEC 61010-1, and IEC 60601-1. These digital isolators have two isolated channels with unidirectional channel configurations. Each isolation channel has a logic input and output buffer separated by a silicon oxide (SiO2) insulation barrier. Used in conjunction with isolated power supplies, these devices prevent noise currents on a data bus or other circuits from entering the local ground and interfering with or damaging sensitive circuitry. The devices have TTL input thresholds and can operate from 3.3- and 5-V supplies. All inputs are 5-V tolerant when supplied from 3.3-V supplies.

Specification Of ISO7520CDWR

Features Of ISO7520CDWR
Highest Signaling Rate: 1 Mbps
Propagation Delay Less Than 20 ns
Low-Power Consumption
Wide Ambient Temperature: –40°C to 105°C
50 kV/µs Transient Immunity Typical
Operates From 3.3-V or 5-V Supply and Logic Levels
3.3-V and 5.0-V Level Translation
Safety and Regulatory Approvals
6000 VPK Isolation per DIN V VDE V 0884-10 and DIN EN 61010-1
4243 VRMS Isolation for 1 Minute per UL 1577
CSA Component Acceptance Notice 5A, IEC 60950-1, IEC 61010-1, and IEC 60601-1 End Equipment Standards
TUV 5000 VRMS Isolation per EN 60950-1 and EN 61010-1
CQC Certification per GB4943.1-2011

Applications Of ISO7520CDWR
Opto-Coupler Replacement in:
Industrial Field-Buses
ProfiBuses
ModBuses
DeviceNet™ Data Buses
Servo Control Interfaces
Motor Control
Power Supplies
Battery Packs
