MAX96707GTG Integrated Circuit Chip 14-Bit GMSL Serializer With Coax/STP Cable Drive

MAX96707GTG Integrated Circuit Chip 14-Bit GMSL Serializer With Coax/STP Cable Drive

Product Description Of MAX96707GTG

MAX96707GTG is a compact serializer in a 4mm × 4mm TQFN package especially suited for automotive camera applications. In high-bandwidth mode, the parallel-clock maximum is 116MHz for 12-bit linear or combined HDR data types.

Specification Of MAX96707GTG

Features Of MAX96707GTG

• Ideal for Safety Camera Applications

• Works with Low-Cost 50Ω Coax (100Ω STP) Cables

• Error Detection of Video/Control Data

• High-Immunity Mode for Robust Control-Channel EMC Tolerance

• Retransmission of Control Data Upon Error Detection

• Best-in-Class Supply Current: 88mA (max)

• Pre/Deemphasis Allows 15m Cable at Full Speed

• 24-Pin (4mm × 4mm) TQFN Package with 0.5mm Lead Pitch

• High-Speed Data Serialization for Megapixel Cameras

• Up to 1.74Gbps Serial-Bit Rate

• 12.5MHz to 87MHz × 12-Bit + H/V Data

• 36.66MHz to 116MHz × 12-Bit + H/V Data (through Internal Encoding)

• Multiple Modes for System Flexibility

• 9.6kbps to 1Mbps Control Channel in I2C Mode (with Clock Stretch)

• Crosspoint Switch Accepts Any Input Bitmap

• Modes for Encoded VSYNC and HSYNC

• Reduces EMI and Shielding Requirements

• Programmable Output Spread Spectrum

• Tracks Spread Spectrum Applied at the Parallel Input

• 1.7V to 1.9V I/O Supply

• Peripheral Features for Camera Power-Up and Verification

• Built-In PRBS Generator for BER Testing

• Dedicated GPO for Camera Frame-Sync Trigger and Other Uses

• Remote/Local Wake-Up from Sleep Mode

• Meets AEC-Q100 Automotive Specification

• -40°C to +115°C Operating Temperature

• ±8kV Contact and ±15kV Air IEC 61000-4-2 and ISO 10605 ESD Protection

Applications Of MAX96707GTG

• Automotive Camera Applications
