NCP57302DSADJR4G Integrated Circuit Chip Low-Dropout Linear Regulator 3A LDO Regulators

NCP57302DSADJR4G Integrated Circuit Chip Low-Dropout Linear Regulator 3A LDO Regulators ​

Product Description Of NCP57302DSADJR4G

NCP57302DSADJR4G is a high precision, very low dropout (VLDO), low minimum input voltage and low ground current positive voltage regulator that is capable of providing an output current in excess of 3.0 A with a typical dropout voltage of 315 mV at 3.0 A load current and input voltage from 1.8 V and up.

NCP57302DSADJR4G is stable with ceramic output capacitors. The device can withstand up to 18 V max input voltage. Internal protection features consist of output current limiting, built-in thermal shutdown and reverse output current protection. Logic level enable pin is available.

NCP57302DSADJR4G is an adjustable voltage device and is available in D2PAK-5 package.

Specification Of NCP57302DSADJR4G

Features Of NCP57302DSADJR4G

Output Current in Excess of 3.0 A
Minimum Operating Input Voltage 1.8 V for Full 3 A Output Current
315 mV Typical Dropout Voltage at 3.0 A
Adjustable Output Voltage Range from 1.24 V to 13 V
Low Ground Current
Fast Transient Response
Switching Power Supply Post Regulation
Stable with Ceramic Output Capacitor
Logic Compatible Enable Pin
Current Limit, Reverse Current and Thermal Shutdown Protection
Operation up to 13.5 V Input Voltage

Applications Of NCP57302DSADJR4G
Consumer and Industrial Equipment Point of Regulation
Servers and Networking Equipment
FPGA, DSP and Logic Power supplies
Switching Power Supply Post Regulation
Battery Chargers
Functional Replacement for Industry Standard MIC29300, MIC39300, MIC37300 with Improved Minimum Input Voltage Specification

Adjustable Regulator Of NCP57302DSADJR4G
