SLG59M1717V Integrated Circuit Chip GreenFET Single N-Channel Load Switch STQFN-16

SLG59M1717V Integrated Circuit Chip GreenFET Single N-Channel Load Switch STQFN-16​

Product Description Of SLG59M1717V

SLG59M1717V is GreenFET Single N-Channel Load Switch IC.
Operating from a 2.5V to 5.5V power supply and fully specified over the -40 °C to 85 °C industrial temperature range, the SLG59M1717V is a high‑performance 4mΩ, 5A single‑channel nFET load switch designed for all 0.8V to 5.5V power rail applications.
SLG59M1717V features adjustable inrush current control which is achieved by adjusting the VOUT slew rate with an external capacitor. Using a proprietary MOSFET design, the SLG59M1717V achieves a stable 4mΩ RDSON across a wide input/supply voltage range.
SLG59M1717V also incorporates resistor‑adjustable current limiting as well as thermal protection. Using proprietary technology for high‑current operation, the SLG59M1717V is packaged in a space‑efficient, low thermal resistance, RoHS‑compliant 1.6mm x 2.5mm STQFN package.

Specification Of SLG59M1717V

Features Of SLG59M1717V

Optimized for all high-side Power-Rail Control Applications in Adapter‑powered Devices, Set‑top Boxes, Tablet PCs, Hard‑disk and Solid‑state Drives, and PCI/PCIe Cards
4mΩ RDSON while supporting 5A
Generates very low thermal gradients
Supply Voltage: 2.5V ≤ VDD ≤ 5.5V
Wide Input Voltage Range: 0.8V ≤ VIN ≤ VDD
Capacitor-adjustable Start-up and In-rush Current Control
Two-stage Overcurrent Protection:
Resistor-adjustable Active Current Limit
Fixed 1.6A Short-circuit Current Limit
Open-drain PG Signaling
Thermal Shutdown Protection
ON-OFF Control: Active HIGH

Applications Of SLG59M1717V

Notebook Power Rail Switching
Tablet Power Rail Switching
Smartphone Power Rail Switching
