STUSB4700QTR Integrated Circuit Chip 400kb/s Stand-Alone USB PD Controller QFN-24

STUSB4700QTR Integrated Circuit Chip 400kb/s Stand-Alone USB PD Controller QFN-24

Product Description Of STUSB4700QTR

STUSB4700QTR is a new family of USB power delivery controllers communicating over Type-C™ configuration channel pin (CC) to negotiate a given amount of power to be sourced to an inquiring consumer device.

Specification Of STUSB4700QTR

Features Of STUSB4700QTR

• USB power delivery (PD) controller
• Type-C attach and cable orientation detection
• Single role: provider
• Full hardware solution - no software
• I2C interface + interrupt (optional connection to MCU)
• Supports up to 5 power data objects (PDO)
• Configurable start-up profiles
• Integrated VBUS voltage monitoring
• Internal and/or external VBUS discharge path
• Short-to-VBUS protections on CC pins (22 V)
• High voltage protections on VBUS pins (28 V)
• High and/or low voltage power supply:
– VSYS = [3.0 V; 5.5 V]
– VDD = [4.1 V; 22 V]
• Automotive grade available
• Fully compatible with:
– USB Type-C™ rev 1.2
– USB PD rev 2.0
– Certification test ID 1030023

Applications Of STUSB4700QTR
• AC adapters and power supplies for: computer, consumer or portable consumer
applications
• Smart plugs and wall adapters
• Power hubs and docking stations
• Displays
• Any Type-C source device
