Integrated Circuit Chip AD5761RBCPZ 16Bit Digital To Analog Converter 16LFCSP IC Chip

Integrated Circuit Chip AD5761RBCPZ 16Bit Digital To Analog Converter 16LFCSP IC Chip


Product Description Of AD5761RBCPZ

AD5761RBCPZ is single channel, 16-/12-bit serial input, voltage output, digital-to-analog converters (DACs).
AD5761RBCPZ operate from single supply voltages from +4.75 V to +30 V or dual supply voltages from −16.5 V to 0 V VSS and +4.75 V to +16.5 V VDD. The integrated output amplifier, reference buffer, and reference provide a very easy to use, universal solution.

Specification Of AD5761RBCPZ

Features Of AD5761RBCPZ

• Low drift 2.5 V reference: ±2 ppm/°C typical
• Total unadjusted error (TUE): 0.1% FSR maximum
• 16-bit resolution: ±2 LSB maximum INL
• Guaranteed monotonicity: ±1 LSB maximum
• Single channel, 16-/12-bit DACs
• Settling time: 7.5 μs typical
• Integrated reference buffers
• Low noise: 35 nV/√Hz
• Low glitch: 1 nV-sec (0 V to 5 V range)
• 1.7 V to 5.5 V digital supply range
