IMT65R057M1H Integrated Circuit Chip 650V 84A Silicon Carbide MOSFET Transistors PG-HSOF-8

IMT65R057M1H Integrated Circuit Chip 650V 84A Silicon Carbide MOSFET Transistors PG-HSOF-8

Product Description Of IMT65R057M1H
IMT65R057M1H CoolSIC™ MOSFET 650 V, 57 mΩ in TOLL package leverages the strengths of the Infineon SiC technology to enable higher density designs and higher switching frequency operations. The small form factor and low parasitic of TOLL allow for an efficient and effective usage of board space as well to drive the MOSFET at higher frequencies, reaching higher power density. CoolSIC™ MOSFET 650 V, 57 mΩ in TOLL package offering is complemented by the availability of TOLL also for CoolMOS™ and CoolGaN™, making it an appealing one stop shop option for various systems. The reduction of thermal impedance compared to D²PAK, together with the innovative .XT interconnect, make the 57 mΩ product suitable for high to mid power systems, with high efficiency targets. It ideally fits the emerging Totem Pole PFC topology in high to mid power systems. It also enables high efficiency and density in DC-DC and AC-DC stages of high to mid power systems. It is also successfully used in interleaved topologies to address high efficiency targets in high power systems.

Features Of IMT65R057M1H

Small form factor
Low parasitic inductance and Kelvin source connection
Reduced thermal impedance
.XT interconnect
Thermal improvement over D²PAK and similar to TO-220
Suitable for wave or reflow soldering
Industry standard package - JEDEC industrial applications qualified

Benefits Of IMT65R057M1H
Enable high system power density and high switching operations
Enable cheaper and faster SMD assembly
Ease of use and compatibility with existing vendors
Reduced switching losses
Lower case temperature and higher reliability
Enables easy design-in with complementing Infineon products like CoolMOS™ and CoolGaN™

Applications Of IMT65R057M1H
Datacenter Power
Telecom power
Solar Inverters
Energy storage systems
Battery formation
Industrial SMPS
Motor drives
Online UPS
