ICM-20602 Sensor IC High Performance 6 Axis MEMS MotionTracking Device LGA16

ICM-20602 Sensor IC High Performance 6 Axis MEMS MotionTracking Device LGA16

Product Description Of ICM-20602

ICM-20602 is a 6-axis MotionTracking device that combines a 3-axis gyroscope, 3-axis accelerometer, in a small 3 × 3 × 0.75 mm (16-pin LGA) package.

ICM-20602 includes on-chip 16-bit ADCs, programmable digital filters, an embedded temperature sensor, and programmable interrupts. The device features an operating voltage range down to 1.71V. Communication ports include I²C and high speed SPI at 10MHz.

Specification Of ICM-20602

Features Of ICM-20602

3-Axis Gyroscope with Programmable FSR of ±250dps, ±500dps, ±1000dps and ±2000dps
3-Axis Accelerometer with Programmable FSR of ±2g, ±4g, ±8g and ±16g
User-programmable interrupts
Wake-on-motion interrupt for low power operation of applications processor
1K byte FIFO buffer enables the applications processor to read the data in bursts
On-Chip 16-bit ADCs and Programmable Filters
Host interface: 10MHz SPI or 400kHz Fast Mode I²C
Digital-output temperature sensor
VDD operating range of 1.71 to 3.45V
MEMS structure hermetically sealed and bonded at wafer level
RoHS and Green compliant

Applications Of ICM-20602
Smartphones and Tablets
Wearable Sensors
IoT Applications
Motion-based game controllers
3D remote controls for Internet connected DTVs and set top boxes, 3D mice
