TPS563201DDCR Integrated Circuit Chip 3A Output Synchronous Step-Down Converter with 580kHz Switching Frequency and D-CAP2 Control Scheme

Description
Part Number: TPS563201DDCR Series: D-CAP2™, Eco-Mode™
Function: Step-Down Current - Output: 3A
Frequency - Switching: 580kHz Operating Temperature: -40°C ~ 125°C (TJ)

TPS563201DDCR Integrated Circuit Chip 3A Output Synchronous Step Down Converter

TPS563201DDCR Integrated Circuit Chip 3A Output Synchronous Step Down Converter

TPS563201DDCR is a simple, easy-to-use, 3A synchronous step-down converter in SOT-23 package. Designed to operate with minimum external component counts, this device achieves low standby current. These switch mode power supply (SMPS) devices employ D-CAP2 control scheme providing fast transient response and support both low equivalent series resistance (ESR) output capacitors such as specialty polymer and ultra-low ESR ceramic capacitors with no external compensation components.

Specifications
Parameter Value
Part Number TPS563201DDCR
Mounting Style SMD/SMT
Package / Case TSOT-23-6
Topology Buck
Output Voltage 760 mV to 7 V
Output Current 3 A
Number of Outputs 1 Output
Input Voltage - Min 4.5 V
Input Voltage - Max 17 V
Quiescent Current 1 mA
Switching Frequency 580 kHz
Minimum Operating Temperature -40 ℃
Maximum Operating Temperature +125 ℃
Input Voltage 4.5 V to 17 V
Operating Supply Current 200 uA
Product Type Switching Voltage Regulators
Shutdown Shutdown
Supply Voltage - Min 4.5 V
Type Synchronous Step-Down Voltage Regulator
Key Features
  • 3A converter integrated 95mΩ and 57mΩ FETs
  • D-CAP2™ control scheme with fast transient response
  • Input voltage range: 4.5V to 17V
  • Output voltage range: 0.76V to 7V
  • Pulse-skip mode
  • 580kHz switching frequency
  • Low shutdown current less than 20µA
  • 2% feedback voltage accuracy (25°C)
  • Startup from prebiased output voltage
  • Cycle-by-cycle overcurrent limit
  • Hiccup-mode overcurrent protection
  • Non-latch UVP and TSD protections
  • Fixed soft start: 1.0ms
Application Fields
  • Digital TV power supply
  • High definition Blu-ray™ disc players
  • Networking home terminal
  • Digital Set Top Box (STB)
  • Surveillance
Other Electronic Components In Stock
