SI5335B-B05117-GMR 200MHz Four-Channel Clock Generator IC with Low Jitter for Precision Timing

Large Image : SI5335B-B05117-GMR 200MHz Four-Channel Clock Generator IC with Low Jitter for Precision Timing

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	SI5335B-B05117-GMR

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	QFN-24
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

SI5335B-B05117-GMR 200MHz Four-Channel Clock Generator IC with Low Jitter for Precision Timing

Description

Part Number:	SI5335B-B05117-GMR	Number Of Outputs::	4 Output
Max Output Freq::	200 MHz	Maximum Input Frequency::	200 MHz
Duty Cycle - Max::	60 %	Jitter::	1 Ps
Highlight:	200MHz Clock Generator , Four-Channel IC Clock Generator , Low Jitter Integrated Circuit Chip

SI5335B-B05117-GMR Integrated Circuit Chip 200MHz Four-Channel Clock Generator

Product Description

The SI5335B-B05117-GMR is a highly flexible clock generator capable of synthesizing four completely non-integer-related frequencies up to 350 MHz. The device features four banks of outputs with each bank supporting one differential pair or two single-ended outputs.

Specifications

Specification	Value
Number of Outputs	4 Output
Max Output Frequency	200 MHz
Maximum Input Frequency	200 MHz
Package/Case	QFN-24
Duty Cycle - Max	60 %
Jitter	1 ps
Supply Voltage - Max	3.63 V
Supply Voltage - Min	1.71 V
Operating Supply Current	45 mA
Minimum Operating Temperature	-40 °C
Maximum Operating Temperature	+85 °C
Operating Supply Voltage	1.8 V, 2.5 V, 3.3 V

Key Features

Low power MultiSynth™ technology enables independent, any-frequency synthesis of four frequencies
Configurable as a clock generator or clock buffer device
Three independent, user-assignable, pin-selectable device configurations
Highly-configurable output drivers with up to four differential outputs, eight single-ended clock outputs, or a combination of both
Low phase jitter of 0.7 ps RMS
Flexible input reference options including external crystal, CMOS input, SSTL/HSTL input, and differential input
Independently configurable outputs support any frequency or format
Independent output voltage per driver: 1.5, 1.8, 2.5, or 3.3 V
Single supply core with excellent PSRR: 1.8, 2.5, 3.3 V
Up to five user-assignable pin functions simplify system design
Loss of signal alarm
PCIe Gen 1/2/3/4 common clock compliant
PCIe Gen 3 SRNS Compliant
Two selectable loop bandwidth settings: 1.6 MHz or 475 kHz
Easy to customize with web-based utility
Compact size: 4 x 4 mm, 24-QFN package
Low power consumption: 45 mA (PLL mode), 12 mA (Buffer mode)
Wide operating temperature range: -40 to +85 °C

Applications

Ethernet switch/router
PCI Express Gen 1/2/3/4
PCIe jitter attenuation
DSL jitter attenuation
Broadcast video/audio timing
Processor and FPGA clocking
MSAN/DSLAM/PON
Fibre Channel, SAN
Telecom line cards
1 GbE and 10 GbE networks
