AD5453YRMZ 14-Bit Multiplying DAC Integrated Circuit Chip 8-Lead MSOP

The AD5453YRMZ is a 14-bit, current output, multiplying digital-to-analog converter for applications that scale an analogue signal rather than a fixed reference. With a plus or minus 10 V reference range, it provides four-quadrant multiplication of the input waveform.

Supply voltage spans 2.5 V to 5.5 V, typical current consumption is below 0.4 uA, and the multiplying bandwidth reaches 12 MHz. The 50 MHz serial interface allows fast code updates and is compatible with standard SPI, QSPI and MICROWIRE control.

Specified from -40 degrees C to +125 degrees C and supplied in an 8-lead MSOP, the AD5453YRMZ is pin compatible with the 8-, 10- and 12-bit versions, making resolution upgrades straightforward in programmable gain and modulation circuits.

The AD5453 family covers several resolution, reference and package options. Because AD5453 devices are pin and software compatible within each package group, a design can move between AD5453 variants without rewriting firmware.

• 14-bit resolution, current output multiplying DAC
• Reference input range plus or minus 10 V
• Four-quadrant multiplication up to 12 MHz
• Supply range 2.5 V to 5.5 V
• Typical current consumption below 0.4 uA
• 50 MHz serial interface
• Pin compatible with 8-, 10- and 12-bit family members
• Operating temperature -40 degrees C to +125 degrees C
• 8-lead MSOP package

• Programmable gain control
• Waveform generation
• Modulation circuits
• Industrial instrumentation
• Communication equipment
• Drop-in upgrades across the AD5453 series

The MSOP version of the AD5453YRMZ keeps the 14-bit multiplying core and 12 MHz bandwidth for leaded signal-chain layouts.
