AD9117

AD9117BCPZN Dual Low Power 14-Bit TxDAC Converter, 40-Lead LFCSP

The AD9117BCPZN is a dual 14-bit low power TxDAC digital to analog converter from the AD9117 series, supplied in a 40-lead LFCSP. Two matched current output cores share a single CMOS input port, keeping power and board area low in portable and high channel count designs.

Power dissipation for the AD9117BCPZN is 191 mW at 10 MSPS and 232 mW at 125 MSPS with a 20 mA output, and sleep mode drops below 3 mW. The supply rail can be anywhere from 1.8 V to 3.3 V, so the converter interfaces directly to modern low voltage logic.

Differential current outputs span 4 mA to 20 mA and two on-chip auxiliary DACs are available for offset or gain trimming. SFDR to Nyquist is 86 dBc at 1 MHz output and 85 dBc at 10 MHz output, with noise spectral density of -157 dBc/Hz at 10 MHz output.

Output common mode is adjustable from 0 V to 1.2 V, which simplifies the interface to a transformer or a differential amplifier such as the AD8130. The exposed pad of the LFCSP must be soldered to a solid ground plane for thermal and noise performance.

The AD9117BCPZN is RoHS compliant and lead free. Full electrical limits, timing and layout guidance are published by Analog Devices, and every order ships with full traceability plus samples and volume pricing on request.

Key Features
  • AD9117 family dual 14-bit TxDAC
  • Two matched current output channels
  • 191 mW at 10 MSPS, 232 mW at 125 MSPS
  • Sleep mode below 3 mW
  • 1.8 V to 3.3 V supply
  • SFDR 86 dBc at 1 MHz output
  • Noise spectral density -157 dBc/Hz at 10 MHz
  • Differential current outputs 4 mA to 20 mA
  • Two on-chip auxiliary DACs
  • Output common mode 0 V to 1.2 V adjustable
  • 40-lead LFCSP package
  • RoHS compliant, lead free
Specifications
SeriesAD9117
Part NumberAD9117BCPZN
FunctionDual low power TxDAC converter
Resolution14 bit
Channels2 main + 2 auxiliary
Supply Voltage1.8 V to 3.3 V
Power Dissipation191 mW at 10 MSPS; 232 mW at 125 MSPS
SFDR86 dBc at 1 MHz output
Output Current4 mA to 20 mA differential
InterfaceCMOS input, single port
Package / Case40-Lead LFCSP
RoHSRoHS compliant, lead free
Typical Applications
  • Portable test and measurement equipment
  • Waveform and signal generation
  • Software defined radio front ends
  • Industrial instrumentation
  • Compact transmit modules

Typical use is dual 14-bit low power analog output in instrumentation and transmit designs.
