LTC1595CIN8 16-Bit Multiplying DACs PDIP-8 Package IC Chip Digital To Analog Converters

LTC1595CIN8 16-Bit Multiplying DACs PDIP-8 Package IC Chip Digital To Analog Converters
LTC1595CIN8 16-Bit Multiplying DACs PDIP-8 Package IC Chip Digital To Analog Converters

Large Image :  LTC1595CIN8 16-Bit Multiplying DACs PDIP-8 Package IC Chip Digital To Analog Converters

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: LTC1595CIN8
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: Standard package
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

LTC1595CIN8 16-Bit Multiplying DACs PDIP-8 Package IC Chip Digital To Analog Converters

Description
Highlight:

LTC1595CIN8 16-Bit Multiplying DACs PDIP-8 Package IC Chip Digital To Analog Converters

,

LTC1595

LTC1595CIN8 Integrated Circuit Chip 16-Bit Multiplying DACs Digital To Analog Converter Chip PDIP-8

The LTC1595CIN8 is a serial 16-bit multiplying digital to analog converter with a current output in an 8-lead package, the C grade in 8-Lead PDIP. It is pin compatible with the industry standard 12-bit DAC8043 and AD7543, so an existing 12-bit socket can be upgraded to 16 bits without a board change.

INL and DNL are 1 LSB maximum, gain error is held to 1 LSB maximum, and glitch impulse is 1 nV-s typical. Settling to 1 LSB takes 2 microseconds when the current output is summed by an external op amp such as the LT1468.

Four-quadrant multiplication means the reference input can swing above and below zero, so the converter works as a programmable gain, attenuator or inverter stage. Power-on reset drives the DAC to zero scale, and the supply current stays at 10 microamps maximum.

A 3-wire SPI and MICROWIRE compatible serial interface carries the 16-bit word, keeping the digital side to three lines. The LTC1595CIN8 ships in 8-Lead PDIP, which suits both surface mount and through-hole assembly depending on the ordering code.

The LTC1595CIN8 is RoHS compliant and lead free, and every order ships with full traceability. Samples and volume pricing are available on request.

Key Features
  • Serial 16-bit multiplying DAC
  • Current output, four-quadrant multiplication
  • INL and DNL 1 LSB maximum over temperature
  • Gain error 1 LSB maximum
  • Low glitch impulse 1 nV-s typical
  • Fast settling to 1 LSB in 2 microseconds with LT1468
  • 3-wire SPI and MICROWIRE compatible interface
  • Power-on reset to zero scale
  • Low supply current 10 microamps maximum
  • Pin compatible with DAC8043 and AD7543
  • 8-Lead PDIP package
  • RoHS compliant, lead free
Specifications
SeriesLTC1595
Part NumberLTC1595CIN8
FunctionSerial 16-bit multiplying DAC
Resolution16 bit
Channels1
OutputCurrent output, four-quadrant multiplication
INL1 LSB maximum
DNL1 LSB maximum
Gain Error1 LSB maximum
Glitch Impulse1 nV-s typical
Settling Time2 microseconds to 1 LSB with LT1468
Supply Current10 microamps maximum
Interface3-wire SPI and MICROWIRE compatible
Power-On ResetZero scale
Package / Case8-Lead PDIP
RoHSRoHS compliant, lead free
Typical Applications
  • Programmable gain and attenuation
  • Digital modulation
  • Waveform generation
  • Instrumentation trim
  • Industrial control loops

Typical use is serial 16-bit multiplying operation in programmable gain and modulation circuits.

MJD Advantage
  • 15+ years of electronic components experience
  • Secure ordering process
  • Excellent customer feedback
  • Confirmed delivery dates
  • Competitive pricing on volume orders
  • Global export experience with responsive after-sales support
Company Profile

Shenzhen Mingjiada Electronics Co., Ltd. is an independent distributor of electronic components from established manufacturers. Founded in Shenzhen in 1996, Mingjiada has established branches in Hong Kong, Japan, Russia, and Taiwan.

Certified under ISO9001:2014 for quality management systems and ISO14001:2014 for environmental management systems. With an experienced team in sales, R&D and management, we specialize in distributing products from more than 500 established suppliers.

Adhering to the principle of "maximizing benefits for customers," we offer comprehensive product ranges and provide high-quality, responsive service through professional logistics and customer service teams.

Quality Assurance
Quality checking and certification process for electronic components
Other Supply Product Types

Related parts we regularly stock and ship in parallel with the series on this page appear below.

Part NumberSeries
MPX2200DPMPX2200
MPX2200GPMPX2200
MPX2202DPMPX2202
MPX2202GPMPX2202
MPX2300DMPX2300
MPXA6115A6UMPXA6115
MPXA6115AC7UMPXA6115
MPXAZ6115AC6T1MPXAZ6115
MPXC2011DT1MPXC2011
MPXH6115A6T1MPXH6115
MPXH6115A6UMPXH6115
MPXH6115AC6T1MPXH6115
MPXH6115AC6UMPXH6115
MPXH6250A6T1MPXH6250
MPXH6250A6UMPXH6250
MPXH6300A6UMPXH6300
MPXHZ6115A6T1MPXHZ6115
MPXHZ6115AC6T1MPXHZ6115
MPXHZ6130A6UMPXHZ6130
MPXHZ6130AUMPXHZ6130
Frequently Asked Questions
Are your LTC1595CIN8 products new stock?
Yes. Every part we ship is new stock sourced through established supply channels, with full traceability.
Which package does the LTC1595CIN8 use?
It is supplied in a 8-Lead PDIP, on tape and reel for automated assembly.
Do you supply the LTC1595CIN8 in tape and reel?
Yes. Standard orders ship in manufacturer tape and reel packaging suitable for automated placement; cut tape and samples are also available on request.
How do you ship my order? Is it safe?
We use express carriers including DHL, FedEx, UPS, TNT, and EMS. We can also use your preferred forwarder. Products are carefully packaged to ensure safety, and we take responsibility for any damage to your order.
What is the lead time for LTC1595CIN8 orders?
Stock parts ship within 5 working days; for non-stock quantities we confirm lead time against your order volume.
