MAX14859GWE Integrated Circuit Chip 5kV Isolated 25Mbps Transceiver with Driver, SOIC Wide Body

The MAX14859GWE is an isolated RS-485/RS-422 transceiver that provides 5 kV RMS of galvanic isolation for 60 seconds between the cable side driver and receiver and the UART side of the device, breaking ground loops between ports at different ground potentials.

Cable side power comes from an integrated LDO, and an integrated transformer driver transfers up to 150mA to the isolated side at around 80% efficiency, so no separate isolated supply module is needed. Data rates reach 25 Mbps, and the receiver loading allows up to 128 devices on one bus.

Protection covers ±35kV human body model ESD on the driver outputs and receiver inputs, ±10kV surge immunity to IEC 61000-4-5, undervoltage lockout and thermal shutdown, while true fail-safe circuitry holds a logic high output when the inputs are shorted or open.

Isolation ratings are 1200 V peak maximum repetitive peak isolation voltage and 848 V RMS maximum working isolation voltage, with a projected lifetime above 30 years at rated working voltage. The device is compliant with the RS-485 EIA/TIA-485 standard.

The MAX14859GWE is supplied in a SOIC Wide Body package. Every order ships as new stock with full traceability, RoHS compliant and lead free, and samples plus volume pricing are available on request.

• 5 kV RMS isolation for 60 seconds
• 25 Mbps maximum data rate
• Integrated LDO for cable side power
• Integrated transformer driver, about 80% efficient at 150mA
• ±35kV HBM ESD on driver outputs and receiver inputs
• ±10kV surge immunity to IEC 61000-4-5
• 1200 V peak maximum repetitive peak isolation voltage
• 848 V RMS maximum working isolation voltage
• Above 30 years lifetime at rated working voltage
• Up to 128 devices on the bus
• True fail-safe receiver
• Undervoltage lockout and thermal shutdown
• RS-485 EIA/TIA-485 compliant
• SOIC Wide Body package

• Isolated RS485 ports in motor drives
• Industrial gateways and protocol converters
• PROFIBUS-DP nodes and repeaters
• Building automation controllers
• Solar and energy storage monitoring
• Multi-point field bus networks

The MAX14859GWE moves the isolation barrier and the isolated power stage into one package, so an isolated RS485 port costs fewer parts and less board area than a discrete design.
