HMC748LC3C Integrated Circuit Chip 13Gbps 2 to 1 Single Ended Selector Multiplexer, 16-Lead LCC

The HMC748LC3C is a 2:1 selector that supports data rates up to 13Gbps and selector port operation up to 13GHz, routing one of the two single ended inputs to the differential output when the select port is asserted.

An output level control pin allows loss compensation or signal level optimization on the differential output, and single ended inputs are terminated with 50 ohm to the positive supply and may be DC or AC coupled.

Rise and fall times are about 22/22 ps, propagation delay is 125ps and typical power consumption is 250 mW, so the part adds negligible jitter to a high speed link. It runs from a single +3.3 V supply.

The HMC748LC3C is supplied in a 16-Lead LCC package with exposed pad. Every order ships as new stock with full traceability, RoHS compliant and lead free, and samples plus volume pricing are available on request.

• Data rates up to 13Gbps
• Selector port operation up to 13GHz
• Single ended inputs, differential or single ended outputs
• Programmable output swing 600mV to 1200mV peak to peak
• Rise and fall times about 22/22 ps
• Propagation delay 125ps
• Low power, 250 mW typical
• Single +3.3 V supply
• 16-Lead LCC package

• High speed serial data routing
• Redundancy switching in telecom line cards
• Test and measurement instruments
• Optical module protection switching
• Clock and data selection up to 13GHz
• Defense electronics

The HMC748LC3C switches a 13Gbps stream between two sources with on chip termination and a programmable output level, so a redundant link can be rerouted without retiming.
