LTC2902-1CGN Programmable Quad Supply Monitor with Margining Control

Production test engineers need to push rails without tripping the supervisor. The LTC2902-1CGN is a programmable quad supply monitor aimed at boards that are tested with margin, because the reset output can be disabled while a rail is deliberately pushed out of window.

Sixteen preset combinations of 5 V, 3.3 V, 3 V, 2.5 V, 1.8 V and 1.5 V are chosen by a resistor divider on the program pin, with any input settable to an adjustable threshold. Supply tolerance is digitally programmable to 5, 7.5, 10 or 12.5 percent below the nominal rail, and threshold accuracy is 1.5 percent over temperature.

Each of the four comparators has its own undelayed output pin, so a failing rail can be identified without reading a register. The reset delay is set by an external capacitor, keeping one part number valid across several power-up profiles.

The reset output is open drain and needs a pullup to the processor logic rail, guaranteed valid with the supply down to 1 V. Supply current is 43 microamps typical in a 16-lead narrow SSOP package.

Key Features
  • Four supplies monitored at once
  • Reset disable pin for margining tests
  • Tolerance programmable to 5, 7.5, 10 or 12.5 percent
  • Individual undelayed output per supply
  • Sixteen preset threshold combinations
  • 1.5 percent threshold accuracy over temperature
  • Capacitor-programmed reset delay
  • Open-drain reset output
  • 43 microamps typical supply current
  • Reset valid with VCC down to 1 V
  • 16-lead narrow SSOP package
  • Lead free and RoHS compliant
Specifications
Product ModelLTC2902
FunctionProgrammable quad supply monitor with margining support
Monitored RailsUp to four supplies
Threshold Options16 presets, 5 V to 1.5 V, or adjustable
Supply Tolerance5, 7.5, 10 or 12.5 percent below nominal
Threshold Accuracy1.5 percent over temperature
Reset OutputOpen drain, active low
Reset DisableProvided for margining
Reset DelaySet by external capacitor
Monitor OutputsOne undelayed output per supply
Supply Current43 microamps typical
Reset Valid Down ToVCC = 1 V
Package16-lead narrow SSOP
ComplianceLead free, RoHS compliant
Typical Applications
  • Telecom and networking equipment
  • Desktop and notebook computers
  • Multivoltage systems
  • Network servers
  • Portable battery-powered equipment
  • Industrial control units
  • Test and measurement instruments
  • Medical monitoring devices

The disable pin exists for production test: a rail can be driven to its margin limits without the supervisor firing, and the same pin restores supervision when the board is released.

MJD Advantage
  • 15+ years of electronic components experience
  • Secure ordering process
  • Excellent customer feedback
  • Confirmed delivery dates
  • Competitive pricing on volume orders
  • Global export experience with responsive after-sales support
Company Profile

Shenzhen Mingjiada Electronics Co., Ltd. is an independent distributor of electronic components from established manufacturers. Founded in Shenzhen in 1996, Mingjiada has established branches in Hong Kong, Japan, Russia, and Taiwan.

Certified under ISO9001:2014 for quality management systems and ISO14001:2014 for environmental management systems. With an experienced team in sales, R&D and management, we specialize in distributing products from more than 500 established suppliers.

Adhering to the principle of "maximizing benefits for customers," we offer comprehensive product ranges and provide high-quality, responsive service through professional logistics and customer service teams.

Quality Assurance
Quality checking and certification process for electronic components
Other Supply Product Types

Other product types we regularly stock and supply appear below.

Part NumberSeries
INA751BIREMRINA751
LM851772QRHARQ1LM85177
LMX2695MPAPSEPLMX2695
OPA591DBVROPA591
REF53125AQDDCRQ1REF53125
M0H3216QRGZRQ1M0H3216QRGZRQ1
M0H3216QRGERQ1M0H3216QRGERQ1
M0H3216QRHBRQ1M0H3216QRHBRQ1
M0H3216QRUKRQ1M0H3216QRUKRQ1
BQ79826ZQPZSRQ1BQ79826
UCC218302BQDFPRQ1UCC21830
OPA2986DGKROPA2986
TCA9849PWRTCA9849
TAS5832DADRTAS5832
TMUX5508RSVRTMUX5508
DRV8003QWRGZRQ1DRV8003
TLV3212QDGKRQ1TLV3212
Frequently Asked Questions
Why disable the reset?
So a rail can be margined during test without the supervisor pulling the processor into reset.
How many tolerance settings are there?
Four: 5, 7.5, 10 and 12.5 percent below the nominal rail.
Are separate monitor outputs available?
Yes, one undelayed output per supply.
Does the reset need a pullup?
Yes, the output is open drain.
What package is used?
16-lead narrow SSOP.
