MSOP8 TPS7A6633QDGNRQ1 LDO Voltage Regulators IC TPS7A6633-Q1

Automobile Chips TPS7A6633QDGNRQ1 LDO Voltage Regulators IC TPS7A6633-Q1 MSOP8

Product Description

TPS7A6633QDGNRQ1 is low-dropout linear regulators designed for up to 40-V Vin operations. With only 12-µA quiescent current at no load, they are quite suitable for standby microprocessor control-unit systems, especially in automotive applications.

Specification Of TPS7A6633QDGNRQ1

Features

• Device Junction Temperature Range: –40°C to +150°C
• 4-V to 40-V Wide Vin Input Voltage Range With up to 45-V Transient
• Output Current: 150 mA
• Low ESR Ceramic Output Stability Capacitor(2.2 µF–100 µF)
• 300-mV Dropout Voltage at 150 mA(Typical, V(Vin) = 4 V)
• Low Input Voltage Tracking
• Integrated Power-On Reset: Programmable Reset-Pulse Delay, Open-Drain Reset Output
• Integrated Fault Protection: Thermal Shutdown, Short-Circuit

Applications

• Infotainment Systems With Sleep Mode
• Body Control Modules
• Always-On Battery Applications
• Gateway Applications
• Remote Keyless Entry Systems
• Immobilizers

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
