Integrated Circuit Chip STM32L452CCU6 Microcontrollers IC STM32L452 UFQFN48

Integrated Circuit Chip STM32L452CCU6 Microcontrollers IC STM32L452 UFQFN48

Product Description

STM32L452CCU6 devices are ultra-low-power microcontrollers based on the high-performance Arm® Cortex®-M4 32-bit RISC core operating at a frequency of up to 80 MHz.
STM32L452CCU6 devices embed high-speed memories (Flash memory up to 512 Kbyte, 160 Kbyte of SRAM), a Quad SPI Flash memories interface (available on all packages) and an extensive range of enhanced I/Os and peripherals connected to two APB buses, two AHB buses and a 32-bit multi-AHB bus matrix.

Specification Of STM32L452CCU6

Features

• Ultra-low-power with FlexPowerControl
• 1.71 V to 3.6 V power supply
• -40 °C to 85/125 °C temperature range
• 145 nA in VBAT mode: supply for RTC and 32x32-bit backup registers
• 22 nA Shutdown mode (5 wakeup pins)
• 106 nA Standby mode (5 wakeup pins)
• 375 nA Standby mode with RTC
• 2.05 uA Stop 2 mode, 2.40 µA with RTC
• 84 uA/MHz run mode (LDO Mode)
• 36 uA/MHz run mode (@3.3 V SMPS Mode)
• Batch acquisition mode (BAM)
• 4 us wakeup from Stop mode
• Brown out reset (BOR)
• Interconnect matrix

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
