400mA Fast Charging Chip SC2150ACFFR USB PD Protocol Chip WLCSP-9

400mA Fast Charging Chip SC2150ACFFR USB PD Protocol Chip WLCSP-9
400mA Fast Charging Chip SC2150ACFFR USB PD Protocol Chip WLCSP-9

Large Image :  400mA Fast Charging Chip SC2150ACFFR USB PD Protocol Chip WLCSP-9

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: SC2150ACFFR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: WLCSP-9
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union

400mA Fast Charging Chip SC2150ACFFR USB PD Protocol Chip WLCSP-9

Description
Part Number: SC2150ACFFR Pull Resistors: 5-kΩ
Current Capability: 400mA Shutdown Mode Power Consumption: As Low As 10uA
VBUS Pin Withstand Voltage: 26V CC Pin Withstand Voltage: 26V
Highlight:

Fast Charging Chip

,

Quick Charge Chip

400mA Fast Charging Chip SC2150ACFFR USB PD Protocol Chip WLCSP-9



Product Description Of SC2150ACFFR

SC2150ACFFR can be controlled via the I2C interface. The SC2150ACFFR is a PHY that supports Type-C interface and supports USB PD2.0, PD3.0 and the latest PD3.1 protocol specification standards.
SC2150ACFFR integrates BMC codec physical layer, supports VBUS voltage detection, VCONN power supply, and 26V CC withstand voltage, so the SC2150A supports data role switching, and can support 100W or higher power transmission with the application processor and power supply.
SC2150ACFFR also supports DFP, UFP, and DRP configurations to meet various Type-C application scenarios..


Features Of SC2150ACFFR

  • Support USB PD3.0 Source, Sink and DRP function
  • Support current capability detection
  • Support plug-in and pull-out detection
  • Built-in VCONN switch with 400mA current capability, supports VCONN switch overcurrent protection
  • Support dead battery mode
  • Support VBUS detection
  • Auto-reply GoodCRC, packet sending failure will automatically resend
  • Support low power standby mode, Shutdown mode power consumption as low as 10uA, sleep mode CC toggle power consumption as low as 50uA, and 26V VBUS pin withstand voltage and 26V CC pin withstand voltage
  • Supports I2C standard mode (up to 100kbps) and I2C fast mode (up to 400kbps with 5-kΩ pull resistors on SCL and SDA pins)
  • 1.235mm x 1.235mm WLCSP-9 package



Functional Diagram Of SC2150ACFFR

400mA Fast Charging Chip SC2150ACFFR USB PD Protocol Chip WLCSP-9 0
