Voltage Regulators IC LMR23615QDRRRQ1 1.5A Synchronous Step Down Converter SON-12

Voltage Regulators IC LMR23615QDRRRQ1 1.5A Synchronous Step Down Converter SON-12

Product Description Of LMR23615QDRRRQ1

LMR23615QDRRRQ1 SIMPLE SWITCHER® is an easyto-use 36 V, 1.5 A synchronous step-down regulator. LMR23615QDRRRQ1 With a wide input range from 4 V to 36 V, the device is suitable for various applications from industrial to automotive for power conditioning from unregulated sources. Peak-current-mode control is employed to achieve simple control loop compensation and cycleby-cycle current limiting. A quiescent current of 75 µA makes it suitable for battery-powered systems. An ultra-low 2-µA shutdown current can further prolong battery life. Internal loop compensation means that the user is free from the tedious task of loop compensation design. This also minimizes the external components.

Specification Of LMR23615QDRRRQ1

Features Of LMR23615QDRRRQ1

• 4V to 36V Input Range
• 1.5A Continuous Output Current
• Integrated Synchronous Rectification
• 60-ns Minimum Switch-On Time
• Internal Compensation for Ease of Use
• Adjustable Switching Frequency
• PFM Mode at Light Load
• Frequency Synchronization to External Clock
• Soft Start into a Prebiased Load
• High Duty-Cycle Operation Supported
• Output Short-Circuit Protection With Hiccup Mode

Applications Of LMR23615QDRRRQ1

• Automotive Infotainment: Clusters, Head Unit, Heads-Up Display
• USB Charging
• General Off-Battery Power Application

Simplified Schematic Of LMR23615QDRRRQ1

Pin Configuration Of LMR23615QDRRRQ1
