STM32H743ZIT6 Microcontroller MCU 32-Bit Single-Core with 480MHz Speed 2MB Flash Memory and 114 I/O Pins

STM32H743ZIT6 Microcontroller MCU 32-Bit Single-Core with 480MHz Speed 2MB Flash Memory and 114 I/O Pins
STM32H743ZIT6 Microcontroller MCU 32-Bit Single-Core with 480MHz Speed 2MB Flash Memory and 114 I/O Pins
STM32H743ZIT6 Microcontroller MCU 32-Bit Single-Core with 480MHz Speed 2MB Flash Memory and 114 I/O Pins STM32H743ZIT6 Microcontroller MCU 32-Bit Single-Core with 480MHz Speed 2MB Flash Memory and 114 I/O Pins STM32H743ZIT6 Microcontroller MCU 32-Bit Single-Core with 480MHz Speed 2MB Flash Memory and 114 I/O Pins

Large Image :  STM32H743ZIT6 Microcontroller MCU 32-Bit Single-Core with 480MHz Speed 2MB Flash Memory and 114 I/O Pins

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: STM32H743ZIT6
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 144-LQFP
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

STM32H743ZIT6 Microcontroller MCU 32-Bit Single-Core with 480MHz Speed 2MB Flash Memory and 114 I/O Pins

Description
Part Number: STM32H743ZIT6 Product Status: Active
Core Processor: ARM® Cortex®-M7 Core Size: 32-Bit Single-Core
Speed: 480MHz Number Of I/O: 114
Highlight:

480MHz Microcontroller MCU

,

2MB Flash Memory STM32H743ZIT6

,

114 I/O Pins 32-Bit Single-Core

STM32H743ZIT6 Microcontroller MCU
32-Bit Single-Core 480MHz 2MB Microcontroller IC in 144-LQFP Package
Product Overview
The STM32H743ZIT6 microcontroller is based on the high-performance Arm® Cortex®-M7 32-bit RISC core operating at up to 480 MHz. The Cortex®-M7 core features a floating point unit (FPU) that supports Arm® double-precision (IEEE 754 compliant) and single-precision data-processing instructions and data types. These devices support a full set of DSP instructions and a memory protection unit (MPU) to enhance application security.
Technical Specifications
Connectivity CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG
Peripherals Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
Number of I/O 114
Program Memory Size 2MB (2M x 8)
Program Memory Type FLASH
RAM Size 1M x 8
Voltage Supply 1.62V ~ 3.6V
Data Converters A/D 36x16b; D/A 2x12b
Oscillator Type Internal
Operating Temperature -40°C ~ 85°C (TA)
Key Features
  • Up to 2 Mbytes of Flash memory with read-while-write support
  • Up to 1 Mbyte of RAM: 192 Kbytes of TCM RAM (including 64 Kbytes of ITCM RAM + 128 Kbytes of DTCM RAM for time critical routines), up to 864 Kbytes of user SRAM, and 4 Kbytes of SRAM in Backup domain
  • Dual mode Quad-SPI memory interface running up to 133 MHz
  • Flexible external memory controller with up to 32-bit data bus: SRAM, PSRAM, SDRAM/LPSDR SDRAM, NOR/NAND Flash memory clocked up to 100 MHz in Synchronous mode
  • CRC calculation unit
Applications
  • Motor drive and application control
  • Medical equipment
  • Industrial applications: PLC, inverters, circuit breakers
  • Printers and scanners
  • Alarm systems, video intercom, and HVAC
NRST Pin Protection
