Product Description Of SAK-XC2365B-40F80LRAB

SAK-XC2365B-40F80LRAB is 16-Bit Single-Chip Microcontroller with 32-Bit Performance, it is a part of the Infineon XC2000 Family of full-feature singlechip CMOS microcontrollers.

SAK-XC2365B-40F80LRAB extend the functionality and performance of the C166 Family in terms of instructions (MAC unit), peripherals, and speed. It combine high CPU performance (up to 80 million instructions per second) with extended peripheral functionality and enhanced IO capabilities.

Specification Of SAK-XC2365B-40F80LRAB

Features Of SAK-XC2365B-40F80LRAB

• High-performance CPU with five-stage pipeline and MPU
– 12.5 ns instruction cycle @ 80 MHz CPU clock (single-cycle execution)
– One-cycle 32-bit addition and subtraction with 40-bit result
– One-cycle multiplication (16 × 16 bit)
– Background division (32 / 16 bit) in 21 cycles
– One-cycle multiply-and-accumulate (MAC) instructions
– Enhanced Boolean bit manipulation facilities
– Zero-cycle jump execution
– Additional instructions to support HLL and operating systems
– Register-based design with multiple variable register banks
– Fast context switching support with two additional local register banks
– 16 Mbytes total linear address space for code and data
– 1,024 Bytes on-chip special function register area (C166 Family compatible)
– Integrated Memory Protection Unit (MPU)

• On-chip memory modules
– 8 Kbytes on-chip stand-by RAM (SBRAM)
– 2 Kbytes on-chip dual-port RAM (DPRAM)
– Up to 16 Kbytes on-chip data SRAM (DSRAM)
– Up to 16 Kbytes on-chip program/data SRAM (PSRAM)
– Up to 320 Kbytes on-chip program memory (Flash memory)
– Memory content protection through Error Correction Code (ECC)
• Up to 12 Mbytes external address space for code and data
– Programmable external bus characteristics for different address ranges
– Multiplexed or demultiplexed external address/data buses
– Selectable address bus width
– 16-bit or 8-bit data bus width
– Four programmable chip-select signals
• Single power supply from 3.0 V to 5.5 V
• Power reduction and wake-up modes
• Programmable watchdog timer and oscillator watchdog
• Up to 76 general purpose I/O lines
• On-chip bootstrap loaders
• On-chip debug support via Device Access Port (DAP) or JTAG interface
• 100-pin Green LQFP package, 0.5 mm (19.7 mil) pitch

Pin Configuration (Top View) Of SAK-XC2365B-40F80LRAB
