DRV8243SQRXYRQ1 Integrated Circuit Chip Automotive H-Bridge Driver With 12A Output 4.5V to 35V Supply and Diagnostics

Description
Part Number: DRV8243SQRXYRQ1 Current - Output: 12A
Voltage - Supply: 4.5V ~ 35V Voltage - Load: 4.5V ~ 35V
Operating Temperature: -40°C ~ 125°C (TA) Package: 14-VFQFN
Highlight:

12A Output H-Bridge Driver

,

4.5V to 35V Supply Automotive Driver

,

Diagnostics Integrated Circuit Chip

DRV8243SQRXYRQ1 Integrated Circuit Chip Automotive H-Bridge Driver With Sense And Diagnostics
Product Overview Of DRV8243

DRV8243 devices are fully integrated H-bridge drivers intended for a wide range of automotive applications. The device can be configured as a single full-bridge driver or as two independent half-bridge drivers.

Specifications Of DRV8243
Part Number DRV8243SQRXYRQ1
Product Status Active
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (2)
Interface PWM, SPI
Technology Bi-CMOS
Applications Automotive
Key Features Of DRV8243
  • 4.5-V to 35-V (40-V abs. max) operating range
  • PWM frequency operation up to 25 KHz with automatic dead time assertion
  • Configurable slew rate and spread spectrum clocking for low electromagnetic interference (EMI)
  • Integrated current sense (eliminates shunt resistor)
  • Proportional load current output on IPROPI pin
  • Configurable current regulation
  • Protection and diagnostic features with configurable fault reaction
  • Supports 3.3-V, 5-V logic inputs
  • Low sleep current - 1μA typical at 25°C
Applications Of DRV8243
  • Automotive brushed DC motors, Solenoids
  • Door modules, mirror modules, and seat modules
  • Body control module (BCM)
  • E-Shifter
  • Gas engine systems
  • On board charger
Simplified Schematic Of DRV8243
DRV8243 Integrated Circuit Simplified Schematic Diagram
