Battery Management LTC6812HLWE-1 15-Cell Battery Stack Monitor With Daisy Chain Interface

Battery Management LTC6812HLWE-1 15-Cell Battery Stack Monitor With Daisy Chain Interface

Product Description Of LTC6812HLWE-1

The LTC6812HLWE-1 is a multicell battery stack monitor that measures up to 15 series connected battery cells with a total measurement error of less than 2.2mV. The cell measurement range of 0V to 5V makes the LTC6812-1 suitable for most battery chemistries. All 15 cells can be measured in 245µs, and lower data acquisition rates can be selected for high noise reduction.

Product Attributes Of LTC6812HLWE-1

Features Of LTC6812HLWE-1

• Measures Up to 15 Battery Cells in Series

• 2.2mV Maximum Total Measurement Error

• Stackable Architecture for High Voltage Systems

• Built-In isoSPI™ Interface

• 1Mb Isolated Serial Communications

• Uses a Single Twisted Pair, Up to 100 Meters

• Low EMI Susceptibility and Emissions

• Bidirectional for Broken Wire Protection

• 245µs to Measure All Cells in a System

• Synchronized Voltage and Current Measurement

• 16-Bit Delta-Sigma ADC with Programmable Noise Filter

• Engineered for ISO 26262-Compliant Systems

• Passive Cell Balancing Up to 200mA (Max) with Programmable Pulse-Width Modulation

• 9 General Purpose Digital I/O or Analog Inputs

• Temperature or Other Sensor Inputs

• Configurable as an I2C or SPI Master

• 6µA Sleep Mode Supply Current

• 64-Lead eLQFP Package

• AEC-Q100 Qualified for Automotive Applications

Applications Of LTC6812HLWE-1

• Electric and Hybrid Electric Vehicles

• Backup Battery Systems

• Grid Energy Storage

• High Power Portable Equipment
