Integrated Circuit Chip ADCLK846BCPZ 1.8 V Low Power Clock Fanout Buffer 24-WFQFN

Integrated Circuit Chip ADCLK846BCPZ 1.8 V Low Power Clock Fanout Buffer 24-WFQFN

Product Description Of ADCLK846BCPZ

ADCLK846BCPZ is a 1.2 GHz/250 MHz, LVDS/CMOS, fanout buffer optimized for low jitter and low power operation. Possible configurations range from 6 LVDS to 12 CMOS outputs,including combinations of LVDS and CMOS outputs. Two control lines are used to determine whether fixed blocks of outputs are LVDS or CMOS outputs.

Specification Of ADCLK846BCPZ

Features Of ADCLK846BCPZ

• Selectable LVDS/CMOS outputs

• Up to 6 LVDS (1.2 GHz) or 12 CMOS (250 MHz) outputs

• <16 mW per channel (100 MHz operation)

• 54 fs integrated jitter (12 kHz to 20 MHz)

• 100 fs additive broadband jitter

• 2.0 ns propagation delay (LVDS)

• 135 ps output rise/fall (LVDS)

• 65 ps output-to-output skew (LVDS)

• Sleep mode

• Pin-programmable control

• 1.8 V power supply

Applications Of ADCLK846BCPZ

• Low jitter clock distribution

• Clock and data signal restoration

• Level translation

• Wireless communications

• Wired communications

• Medical and industrial imaging

• ATE and high performance instrumentation
