ICs Chip AD8418WBRZ Bidirectional Zero Drift Current Sense Amplifier IC 8-SOIC

ICs Chip AD8418WBRZ Bidirectional Zero Drift Current Sense Amplifier IC 8-SOIC

Product Description Of AD8418WBRZ

AD8418WBRZ is a high voltage, high resolution current shunt amplifier. It features an initial gain of 20 V/V, with a maximum ±0.15% gain error over the entire temperature range. The buffered output voltage directly interfaces with any typical converter.

Specification Of AD8418WBRZ

Features Of AD8418WBRZ

• Typical 0.1 µV/°C offset drift

• Maximum ±400 µV voltage offset over full temperature range

• 2.7 V to 5.5 V power supply operating range

• Electromagnetic interference (EMI) filters Included

• High common-mode input voltage range

• 2 V to +70 V operating

• 4 V to +85 V survival

• Initial gain = 20 V/V

• Wide operating temperature range: −40°C to +125°C

• Bidirectional operation

• Available in 8-lead SOIC and 8-lead MSOP

• Common-mode rejection ratio (CMRR): 86 dB, dc to 10 kHz

Applications Of AD8418WBRZ

• High-side current sensing

• Motor controls

• Solenoid controls

• Power management

• Low-side current sensing

• Diagnostic protection
