4N-Channel Mosfet Array MSCSM170HM23CT3AG Full Bridge SiC MOSFET Power Module 602W

Description

Part Number:	MSCSM170HM23CT3AG	Power Dissipation TC = 25 °C:	602W(Max)
Drain-Source ON Resistance(Max):	22.5mΩ	Gate–Source Leakage Current(VGS = 20 V; VDS = 0 V):	200nA(Max)
Internal Gate Resistance(Typ):	2.93Ω	Junction-to-case Thermal Resistance(Max):	0.25°C/W

4N-Channel Mosfet Array MSCSM170HM23CT3AG Full Bridge SiC MOSFET Power Module 602W

Product Description Of MSCSM170HM23CT3AG

MSCSM170HM23CT3AG is Full Bridge SiC MOSFET Power Module, 1700 V, 124 A silicon carbide (SiC) Mosfet Array module.

Specification Of MSCSM170HM23CT3AG

Part Number	MSCSM170HM23CT3AG
Technology	Silicon Carbide (SiC)
Configuration	4 N-Channel (Full Bridge)
Drain to Source Voltage (Vdss)	1700V (1.7kV)
Current - Continuous Drain (Id) @ 25°C	124A (Tc)
Rds On (Max) @ Id, Vgs	22.5mOhm @ 60A, 20V
Vgs(th) (Max) @ Id	3.2V @ 5mA
Gate Charge (Qg) (Max) @ Vgs	356nC @ 20V
Input Capacitance (Ciss) (Max) @ Vds	6600pF @ 1000V
Power - Max	602W (Tc)
Operating Temperature	-40°C ~ 175°C (TJ)
Mounting Type	Chassis Mount
Package / Case	Module

Electrical Schematic Of MSCSM170HM23CT3AG

Other Supply Product Types

Part Number	Package
UCC24610DRBR	SON8
TPS65286RHDR	VQFN28
ADS1294IPAG	TQFP64
DS90LV017ATMX	SOP-8
NTD4906NT4G	TO-252
EL5420CRZ	TSSOP14
