SOT-563 Surface Mount TPS563231DRLR 3A Synchronous Step-Down Voltage Regulator

SOT-563 Surface Mount TPS563231DRLR 3A Synchronous Step-Down Voltage Regulator

Product Description Of TPS563231DRLR

TPS563231DRLR is a simple, easy-to-use, 3-A synchronous step-down converter in SOT563 package.
TPS563231DRLR device is optimized to operate with minimum external component counts and also optimized to achieve low standby current.

Specification Of TPS563231DRLR

Features Of TPS563231DRLR

• 3-A Converter integrated 95-mΩ and 55-mΩ FETs

• D-CAP3™ mode control with fast transient response

• Input voltage range: 4.5 V to 17 V

• Output voltage range: 0.6 V to 7 V

• Pulse skip mode

• 600-kHz switching frequency

• Low shutdown current Less than 12 µA

• 2% Feedback voltage accuracy (25ºC)

• Startup from pre-biased output voltage

• Cycle-by-cycle over current limit

• Hiccup-mode over current protection

• Non-latch UVP and TSD protections

• 6-Pin SOT563 package

Applications Of TPS563231DRLR

• Digital TV power supply

• High definition Blu-ray™ disc players

• Networking home terminal

• Digital set top box (STB)

• Surveillance
