IC Chip MSC015SMA070B N-Channel 700V Through Hole TO-247-3 Transistors

Large Image : IC Chip MSC015SMA070B N-Channel 700V Through Hole TO-247-3 Transistors

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	MSC015SMA070B

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	TO-247-3
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

IC Chip MSC015SMA070B N-Channel 700V Through Hole TO-247-3 Transistors

Description

Part Number:	MSC015SMA070B	FET Type:	N-Channel
Drive Voltage:	20V	Power Dissipation:	400W (Tc)
Mounting Type:	Through Hole	Unit Weight:	6 G

IC Chip MSC015SMA070B N-Channel 700V Through Hole TO-247-3 Transistors

Product Description Of MSC015SMA070B

MSC015SMA070B device is a 700 V, 15 mΩ SiC MOSFET in a TO-247 package.

Specification Of MSC015SMA070B

Part Number	MSC015SMA070B
Vds - Drain-Source Breakdown Voltage:	700 V
Id - Continuous Drain Current:	140 A
Rds On - Drain-Source Resistance:	19 mOhms
Vgs - Gate-Source Voltage:	- 10 V, + 25 V
Vgs th - Gate-Source Threshold Voltage:	1.9 V
Qg - Gate Charge:	215 nC
Minimum Operating Temperature:	- 55 C
Maximum Operating Temperature:	+ 175 C
Pd - Power Dissipation:	400 W

Features Of MSC015SMA070B

Fast switching speed due to low internal gate resistance (ESR)
Fast and reliable body diode
RoHS compliant
