Integrated Circuit Chip IKW50N120CH7XKSA1 Single IGBT Transistors TO-247-3

Large Image : Integrated Circuit Chip IKW50N120CH7XKSA1 Single IGBT Transistors TO-247-3

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	IKW50N120CH7XKSA1

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	TO-247-3
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

Integrated Circuit Chip IKW50N120CH7XKSA1 Single IGBT Transistors TO-247-3

Description

Part Number:	IKW50N120CH7XKSA1	Switching Energy:	2.33mJ (on), 1.12mJ (off)
Input Type:	Standard	Gate Charge:	375 NC
Mounting Type:	Through Hole	Voltage - Collector Emitter Breakdown:	1200 V

Integrated Circuit Chip IKW50N120CH7XKSA1 Single IGBT Transistors TO-247-3

Product Description Of IKW50N120CH7XKSA1

IKW50N120CH7XKSA1 enables battery voltages up to 470V and safe fast switching due to increased overvoltage margins.

Specification Of IKW50N120CH7XKSA1

Part Number	IKW50N120CH7XKSA1
Current - Collector Pulsed (Icm)	200 A
Vce(on) (Max) @ Vge, Ic	2.15V @ 15V, 50A
Power - Max	398 W
Switching Energy	2.33mJ (on), 1.12mJ (off)
Input Type	Standard
Gate Charge	375 nC

Features Of IKW50N120CH7XKSA1

Simple gate drive design
Self-limiting current under short circuit condition
Low EMI signature
High reliability and operating lifetime

Other Supply Product Types

Part Number	Package
ESD8040MUTAG	UDFN18
505270-2010	SMD
HVLED001TR	SSOP-10
LAN9311-NZW	QFP128
RTL8201CP	LQFP48
A6SN-2102-P	SMD

FAQ

Q: Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q: Which Certificates do you have?
A: We are ISO 9001:2015 Certified Company and member of ERAI.
Q: Can you support small quantity order or sample?Is the sample free?
A: Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q: How to ship my order? Is it safe?
A: We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q: What about the lead time?
A: We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
