Product Details:
|
| Part Number: | NXH80T120L3Q0S3G | Current - Collector Cutoff (Max): | 300 µA |
|---|---|---|---|
| Vce(on) (Max) @ Vge, Ic: | 2.4V @ 15V, 80A | Power - Max: | 188 W |
| Current - Collector (Ic) (Max): | 75 A | Voltage - Collector Emitter Breakdown (Max): | 1200 V |
| Highlight: | Trench Field Stop Automotive IGBT Modules,NXH80T120L3Q0S3G Automotive IGBT Modules,NXH80T120L3Q0S3G Trench Field Stop IGBT |
||
Trench Field Stop Automotive IGBT Modules 1200V NXH80T120L3Q0S3G
IGBT Module Trench Field Stop NXH80T120L3Q0S3G Automotive IGBT Modules 1200V
Product Description Of NXH80T120L3Q0S3G
NXH80T120L3Q0S3G is 1200V 75A 188W IGBT Module Trench Field Stop Half Bridge.
Specification Of NXH80T120L3Q0S3G
| Part Number | NXH80T120L3Q0S3G |
|
Input Capacitance (Cies) @ Vce
|
18.15 nF @ 20 V
|
|
Input
|
Standard
|
|
NTC Thermistor
|
Yes
|
|
Operating Temperature
|
-40°C ~ 175°C (TJ)
|
|
Mounting Type
|
Chassis Mount
|
|
Package / Case
|
Module
|
|
Supplier Device Package
|
20-PIM/Q0PACK (55x32.5)
|
Pin Assignments Of NXH80T120L3Q0S3G
