IGBT 3 Phase Inverter Module NXH40T120L3Q1PG Chassis Mount 1200V 40A

Large Image : IGBT 3 Phase Inverter Module NXH40T120L3Q1PG Chassis Mount 1200V 40A

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	NXH40T120L3Q1PG

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	Module
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

IGBT 3 Phase Inverter Module NXH40T120L3Q1PG Chassis Mount 1200V 40A

Description

Part Number:	NXH40T120L3Q1PG	Configuration:	3-Phase Inverter
Collector-Emitter Saturation Voltage:	1.85 V	Gate-Emitter Leakage Current:	800 NA
Continuous Collector Current At 25 C:	40 A	Collector- Emitter Voltage VCEO Max:	1.2 KV
Highlight:	IGBT 3 Phase Inverter Module , NXH40T120L3Q1PG 3 Phase Inverter Module , NXH40T120L3Q1PG

IGBT 3 Phase Inverter Module NXH40T120L3Q1PG Chassis Mount 1200V 40A

Three Phase IGBT Module NXH40T120L3Q1PG 1200V Automotive IGBT Modules 40A

Product Description Of NXH40T120L3Q1PG

NXH40T120L3Q1PG is 1200V, 40A Q1 3-Phase TNPC Module, Chassis Mount.

Specification Of NXH40T120L3Q1PG

Part Number:	NXH40T120L3Q1PG
Continuous Collector Current at 25 C:	40 A
Gate-Emitter Leakage Current:	800 nA
Pd - Power Dissipation:	145 W
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 150 C

Pin Connections Of NXH40T120L3Q1PG

IGBT 3 Phase Inverter Module NXH40T120L3Q1PG Chassis Mount 1200V 40A 0
