Integrated Silicon MPX5010DP Pressure Sensor 1.45PSI 10kPa Differential

Integrated Silicon MPX5010DP Pressure Sensor 1.45PSI 10kPa Differential

Product Description Of MPX5010DP

The MPX5010DP piezoresistive transducers are state-of-the-art monolithic silicon pressure sensors designed for a wide range of applications, but particularly those employing a microcontroller or microprocessor with A/D inputs.

Product Attributes Of MPX5010DP

Features Of MPX5010DP

• 5.0% Maximum Error over 0 to 85C
• Ideally Suited for Microprocessor or Microcontroller-Based Systems
• Durable Epoxy Unibody and Thermoplastic (PPS) Surface Mount Package
• Temperature Compensated over -40 to +125C
• Patented Silicon Shear Stress Strain Gauge
• Available in Differential and Gauge Configurations
• Available in Surface Mount (SMT) or Through-hole (DIP) Configurations

Applications Of MPX5010DP

• Hospital Beds
• HVAC
• Respiratory Systems
• Process Control
• Washing Machine Water Level Measurement (Reference AN1950)
• Ideally Suited for Microprocessor or Microcontroller-Based Systems
• Appliance Liquid Level and Pressure
• Measurement

Function Block Diagram Of MPX5010DP
