TLE92108-232QX Integrated Circuit Chip Non-Inverting Half-Bridge Gate Driver IC 48-VFQFN

 Integrated Circuit Chip TLE92108-232QX Non-Inverting Half-Bridge Gate Driver IC 48-VFQFN

Product Description Of TLE92108-232QX

TLE92108-232QX is a Multi-MOSFET driver IC dedicated to control up to sixteen n-channel MOSFETs. Itincludes eight half bridges for DC motor control applications such as automotive power seat control or otherapplications.

Specification Of EP4CE15F23C8N

Features Of TLE92108-232QX

• Eight half-bridge gate drivers for external N-channel MOSFETs

• Control of reverse battery protection MOSFET

• Adaptive MOSFET gate control– Improved electromagnetic emission– Reduced switching losses in PWM mode

• 24-bit Serial Peripheral Interface

• Two current sense amplifiers with configurable gain– High-side and low-side capable for protection and diagnosis

• Drain-source monitoring for short circuit detection

• Overtemperature warning and shutdown

• Timeout watchdog

• Detailed off-state diagnostic (open load, short circuit to battery or short circuit to GND) via SPI

• Three PWM inputs– High-side and low-side PWM capable– Active free-wheeling– Up to 25 kHz PWM frequency

• Low current consumption in sleep mode

• Configurable low-side 1-4 brake with short circuit detection in sleep mode and normal mode

• Configurable VS overvoltage detection in sleep mode

• Leadless power package with support of optical lead tip inspection

• Green Product (RoHS compliant)

• AEC Qualified

Applications Of TLE92108-232QX

• Seat control and extended functions (steering column adjustment, gas pedal adjustment)

• Power lift gate

• Central door lock

• Body control module (cargo cover, washer pump, window lift, rear wiper)
