TLE5009 E2010 Ic Chip Angle Sensor With Analog Outputs SOP-8 Package

 TLE5009 E2010 Angle Sensor With Analog Outputs SOP-8 Package

Product Description Of TLE5009 E2010
TLE5009 E2010 is an angle sensor with analog outputs. It detects the orientation of a magnetic field by measuring sine and cosine angle components with Giant Magneto Resistance (GMR) elements. It provides analog sine and cosine output voltages that describe the magnet angle in a range of 0 to 360°. The differential GMR bridge signals are temperature compensated and independent of the magnetic field strength to maintain constant output voltage over a wide temperature and field range.

Features Of TLE5009 E2010

• 3V to 5.5V operating supply voltage

• Low current consumption and very quick start up

• Overvoltage detection

• 360° contactless angle measurement

• Output amplitude optimized for circuits with 3.3V or 5V supply voltage (type -E10x0 or -E20x0 respectively)

• Immune to air-gap variations due to GMR based sensing principle

• Output amplitude constant over a wide temperature range: -40°C to 150°C (junction temperature)

• High accuracy typically 0.6° overall angle error

• AEC-Q100 automotive qualified

• Green package with lead-free (Pb-free) plating


Applications Of TLE5009 E2010

• Rotor position sensing for electric motor commutation

• Rotary switches

• Steering angle sensing

• Valve or flap position sensing
