General Purpose Amplifier TLV9044IDYYR 10µA Micro-Power RRIO Amplifier IC 14-SOIC

General Purpose Amplifier TLV9044IDYYR 10µA Micro-Power RRIO Amplifier IC 14-SOIC​

Product Description Of TLV9044IDYYR

TLV9044IDYYR is 1.2V Ultra Low Voltage, 10µA Micro-Power RRIO Amplifier for Power Conscious Applications.
TLV9044IDYYR enables power savings both with its low quiescent current (10µA, typ.) and the ability to operate at supply voltages as low as 1.2V, making it one of the few amplifiers in the industry capable of 1.5V coin cell applications.

Specification Of TLV9044IDYYR

Features Of TLV9044IDYYR

• Low power CMOS amplifier for cost-optimized applications
• Operational from supply voltage as low as 1.2 V
• Low input bias current: 1pA typical, 12pA maximum
• Low quiescent current: 10 µA/ch
• Low integrated noise of 6.5 µVp-p in 0.1 Hz – 10 Hz
• Rail-to-rail input and output
• High gain bandwidth product: 350 kHz
• Thermal noise floor: 64 nV/√Hz
• Low input offset voltage: ±0.6 mV
• Unity-gain stable
• Robustly drives 100 pF of load capacitance
• Internal RFI and EMI filtered input pins
• Wide specified temperature range: –40°C to 125°C

Applications Of TLV9044IDYYR

• Portable electronics
• Wearable fitness and activity monitor
• Headsets/headphones and earbuds
• Personal electronics
• Building automation
• Wearables (non-medical)
• Motion detector (PIR, uWave, etc.)
• Electronic point of sales (EPOS)
• Single-supply, low-side, unidirectional currentsensing circuit

Functional Block Diagram Of TLV9044IDYYR
