Optical Sensors AR0330CM1C12SHKA0-CP CMOS Digital Image Sensor 64-VFBGA

Optical Sensors AR0330CM1C12SHKA0-CP CMOS Digital Image Sensor 64-VFBGA

Product Description Of AR0330CM1C12SHKA0-CP

AR0330CM1C12SHKA0-CP is a 1/3-inch CMOS digital image sensor with an active-pixel array of 2304 (H) × 1536 (V). It can support 3.15 Mp (2048 (H) × 1536 (V)) digital still image capture and a 1080p60 + 20% EIS (2304 (H) × 1296 (V)) digital video mode. It incorporates sophisticated on-chip camera functions such as windowing, mirroring, column and row sub-sampling modes, and snapshot modes.

Specification Of AR0330CM1C12SHKA0-CP

Feature Of AR0330CM1C12SHKA0-CP

• 2.2 µm pixel with ON Semiconductor A-Pix™ technology

• Full HD support at 60 fps (2304H x 1296V) for maximum video performance

• Superior low-light performance

• 3.4Mp (3:2) and 3.15 Mp (4:3)still images

• Support for external mechanical shutter

• Support for external LED or Xenon flash

• Data interfaces: four-lane serial high-speed pixel

• interface (HiSPi™) differential signaling (SLVS), four-lane serial MIPI interface, Parallel

• On-chip phase-locked loop (PLL) oscillator

• Simple two-wire serial interface

• Auto black level calibration

• 12-to-10 bit output A-Law compression

• Slave mode for precise frame-rate control and for synchronizing two sensors

Appiacations Of AR0330CM1C12SHKA0-CP

• 1080p High-definition Digital Video Camcorder

• Web Cameras and Video Conferencing Cameras

• Security
