ADUM342E0WBRWZ Integrated Circuit Chip 5700Vrms Quad-Channel Digital Isolators
ADUM342E0WBRWZ is a 5700Vrms quad-channel digital isolator, available in various configurations with a withstand voltage rating of 5.7 kV rms. It operates with supply voltages ranging from 2.25 V to 5.5 V on either side, ensuring compatibility with lower voltage systems and enabling voltage translation across the isolation barrier.
Product Attributes
| Technology |
Magnetic Coupling |
| Type |
CAN, RS485, SPI |
| Isolated Power |
Yes |
| Number of Channels |
4 |
| Inputs - Side 1/Side 2 |
2/2 |
| Channel Type |
Unidirectional |
| Voltage - Isolation |
5700Vrms |
| Common Mode Transient Immunity (Min) |
100kV/µs |
| Data Rate |
150Mbps |
| Propagation Delay tpLH / tpHL (Max) |
10ns, 10ns |
| Pulse Width Distortion (Max) |
3ns |
| Rise / Fall Time (Typ) |
2.5ns, 2.5ns |
| Voltage - Supply |
2.25V ~ 5.5V |
| Operating Temperature |
-40°C ~ 125°C |
| Mounting Type |
Surface Mount |
| Package / Case |
16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package |
16-SOIC |
Features
- High common-mode transient immunity: 180 kV/µs typical
- High robustness to radiated and conducted noise
- Low propagation delay: 6.2 ns typical (10 ns maximum) for 5 V operation
- Low dynamic power consumption, <1.65 mA/ch at 1 Mbps
- 2.25 V to 5.5 V level translation
- 150 Mbps maximum guaranteed data rate for 5 V operation
- High temperature operation: 125°C
- ±8 kV IEC 61000-4-2 ESD protection across isolation barrier
- ±5 kV HBM ESD protection on input/output pins
- Fail-safe high (E1) or low (E0) options
- 16-lead, RoHS compliant, SOIC package
Applications
- Serial peripheral interface (SPI) data converter isolation
- RS-485 and controller area network with flexible data rate (CAN FD) industrial field bus isolation
- PWM controller signal isolation
- General-purpose multichannel isolation
