ADUM4135WBRWZ Integrated Circuit Chip 4.61A 5000Vrms Single-Channel Gate Driver IC SOIC16

ADUM4135 is a single-channel gate driver specifically optimized for driving insulated gate bipolar transistors (IGBTs). ADUM4135 includes a Miller clamp to provide robust IGBT turn-off with a single-rail supply when the gate voltage drops below 2 V (typical). Operation with unipolar or bipolar secondary supplies is possible, with or without the Miller clamp operation.

• 13 A short-circuit source current (0 Ω gate resistance)
• 14 A short-circuit sink current (0 Ω gate resistance)
• 4.61 A peak current (2 Ω gate resistance)
• Output power device resistance: <1 Ω
• Desaturation protection
• Isolated desaturation fault reporting
• Soft shutdown on fault
• Miller clamp output with gate sense input
• Isolated fault and ready functions
• Low propagation delay: 55 ns typical
• Minimum pulse width: 50 ns
• Operating temperature range: −40°C to +125°C
• Output voltage range to 30 V
• Input voltage range from 2.5 V to 6 V
• Output and input undervoltage lockout (UVLO)
• Creepage distance: 7.8 mm minimum
• 100 kV/μs common-mode transient immunity (CMTI)
• 20-year lifetime for 600 V rms or 1092 V dc working voltage
• Safety and regulatory approvals
• 5 kV ac for 1 minute per UL 1577
• CSA Component Acceptance Notice 5A
• DIN VDE V 0884-11:2017-01
• VIORM = 849 V peak (reinforced)
• Qualified for automotive applications

• MOSFET/IGBT gate drivers
• PV inverters
• Motor drives
• Power supplies
• Automotive
