Product Description Of GL9750

GL9750 is a PCI Express Rev. 1.1 compliant card reader controller which integrates PCI Express PHY, memory card access interface, regulators (3.3V-to-1.2V) and card power switch.

Features Of GL9750

• Compliant with PCI Express Base Specification Rev. 1.1
• Support 1-Lane 2.5 Gbps PCI Express Bus
• Support SD CPRM function
• Support PCI Express Clock Request (CLK_REQ#)
• Support PCI Express ASPM L0s / L1
• Support PCI Express L1 sub-states (L1.1 and L1.2) and RTD3 (Runtime D3 cold)
• Support PCI Express LTR (Latency Tolerance Reporting) and OBFF (Optimized Buffer Flush/Fill)
• Support Modern Standby
• High efficiency hardware DMA engine to improve data transfer performance
• On-chip 3.3V to 1.2V regulator for core and analog macros
• On-chip 3.3V power switch for SD card power (800 mA)
• Support Over-current protection mechanism
• Support Spread Spectrum Clock (SSC) for SD to reduce EMI effect
• Available in QFN32 4mmx4mm package
