Integrated Circuit Chip MAX98360AENL 1-Channel Class-D Audio Amplifier 9-XFBGA

Integrated Circuit Chip MAX98360AENL 1-Channel Class-D Audio Amplifier 9-XFBGA​

Product Description Of MAX98360AENL

MAX98360AENL is an easy-to-use, low-cost, digital pulse-code modulation (PCM) input Class-D amplifier that provides industry-leading, Class-AB audio performance with Class-D efficiency.

Specification Of MAX98360AENL

Features Of MAX98360AENL

• Simple Plug-and-Play Design
• Single-Supply Operation (2.5V to 5.5V)
• 3.2W Output Power into 4Ω at 5V
• 2.2mA Quiescent Current
• 92% Efficiency (RL = 8Ω, THD+N = 10%)
• 10μVRMS Output Noise
• 110dB Dynamic Range
• Low 0.009% THD+N at 1kHz
• No MCLK Required
• Sample Rates of 8kHz to 96kHz
• Supports Left, Right, or (Left/2 + Right/2) Output in I2S and Left-Justified Modes
• Sophisticated Edge Rate Control Enables Filterless Class-D Outputs
• 81dB PSRR at 217Hz
• 1.5μA Standby Current Allows Elimination of GPIO for EN Pin
• Low RF Susceptibility Rejects TDMA Noise from GSM Radios
• Class-D Switching Frequency Trimmed to 5% for Better EMI Planning
• Extensive Click-and-Pop Reduction Circuitry
• Robust Short-Circuit and Thermal Protection

Applications Of MAX98360AENL

• Single Li-ion Cell/5V Devices
• Smart Speakers
• Notebook Computers
• IoT Devices
• Gaming Devices (Audio and Haptics)
• Smartphones
• Tablets
• Cameras
