MPQ2178GQHE-AEC1-Z Integrated Circuit Chip 2A 2.4MHz Synchronous Step-Down Converter With Power Good And Soft Start
MPQ2178GQHE-AEC1-Z Integrated Circuit Chip 2A 2.4MHz Synchronous Step-Down Converter With Power Good And Soft Start
Description
Part Number:
MPQ2178GQHE-AEC1-Z
Output Voltage::
600 MV
Output Current::
2 A
Number Of Outputs::
1 Output
Input Voltage - Min::
2.5 V
Input Voltage - Max::
5.5 V
MPQ2178GQHE-AEC1-Z Integrated Circuit Chip 2A 2.4MHz Synchronous Step-Down Converter With Power Good And Soft Start
Product Description Of MPQ2178GQHE-AEC1-Z
MPQ2178GQHE-AEC1-Z is a monolithic, step-down, switch-mode converter with built-in internal power MOSFETs. It achieves 2A of continuous output current across a 2.5V to 6V input voltage range, with excellent load and line regulation. The output voltage (VOUT) can be regulated to as low as 0.6V.
Specifications Of MPQ2178GQHE-AEC1-Z
600 mV
2 A
1 Output
2.5 V
5.5 V
460 uA
2.4 MHz
- 40 C
+ 125 C
Input Voltage:
2.5 V to 5.5 V
Feature Of MPQ2178GQHE-AEC1-Z
• Designed for Automotive Applications:
Wide 2.5V to 6V Operating Input Voltage Rangeo Up to 2A Output Current
1% FB Accuracyo Junction Temperature Operation from -40°C to +150°C
• High Performance for Improved Thermals:
70mΩ and 40mΩ Internal Power MOSFETs
• Optimized for EMC and EMI Reduction:
2.4MHz Switching Frequency
FCCM across Full Load Range
MeshConnectTM Flip-Chip Package
• Optimized for Board Size and BOM:
Built-in Internal Power MOSFETs
Integrated Compensation Network
Fixed Output Options: 0.7V, 0.75V,0.8V, 0.85V, 0.88V, 0.9V, 1.05V, 1V,1.1V, 1.2V, 1.25V, 1.5V, 1.8V, 2.5V,2.8V, and 3.3V
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
