Integrated Circuit Chip ISL9122AIIHZ Buck Boost Regulator With Bypass WLCSP-8

Integrated Circuit Chip ISL9122AIIHZ Buck Boost Regulator With Bypass WLCSP-8​

Product Description Of ISL9122AIIHZ

ISL9122AIIHZ is a highly integrated non-inverting buck-boost switching regulator that accepts input voltages both above or below the regulated output voltage. It features an extremely low quiescent current consumption of 1300nA in Regulation mode, 120nA in Forced Bypass mode, and 8nA in Shutdown mode. It supports input voltages from 1.8V to 5.5V.

Feature Of ISL9122AIIHZ

• 1300nA quiescent current
• 84% efficiency at 10µA load (VIN = 3.6V, VOUT = 3.3V)
• 97% peak efficiency (VIN = 3.6V, VOUT = 3.3V)
• Input voltage range: 1.8V to 5.5V
• Output voltage range: 1.8V to 5.375V
• Output current: up to 500mA (VIN > VOUT > 2.5V)
• Selectable Forced and Auto Bypass power saving modes
• Seamless PWM/PFM and buck/boost transition
• I2C control and voltage adjustability
• Hysteretic controller
• Small 1.8mm×1.0mm 8 Bump WLCSP

Applications Of ISL9122AIIHZ

• Smart watches and wristband devices
• Wireless earphones
• Internet of Things (IoT) devices
• Water, gas, and oil meters
• Portable medical devices
• Hearing aid devices
