Product Description Of ST75MMTR

ST75MMTR is a flexible power line communication System on Chip combining a high-performing PHY processor and a protocol controller core, implementing the turnkey METERS AND MORE protocol standard along with the fully integrated analog front end (AFE) and line driver in a single chip, for future-proof, compact and cost effective Smart Grid solutions.

Specification Of ST75MMTR

Features Of ST75MMTR

• METERS AND MORE standard compliant power line communication System on Chip
• High-performing, configurable DSP core for flexible PHY layer processing
• 8-bit protocol engine embedding turnkey METERS AND MORE compliant data link layer
• Up to 57.6 kbps host controller UART interface
• Embedded AES-128 encryption engine for data authentication and confidentiality services
• 8 to 18 V power amplifier supply
• 3.3 V or 5 V digital i/o supply
• Embedded zero-crossing detection for line phase recognition
• Suitable for CENELEC EN50065, ARIB and FCC part 15 compliant applications
• Communication carrier frequency programmable up to 250 kHz
• VFQFPN48 7 x 7 exposed pad package
• -40 °C to +85 °C temperature range

Applications Of ST75MMTR

• METERS AND MORE standard compliant advanced metering infrastructures (AMI)
• Sub-metering and Smart Grid applications
• Command and control networks
• Smart home applications
