Product Description Of LM5168FDDAR

LM5168FDDAR synchronous buck converters is designed to regulate over a wide input voltage range, minimizing the need for external surge suppression components. A minimum controllable on time of 50ns facilitates large step-down conversion ratios, enabling the direct step-down from a 48V nominal input to low-voltage rails for reduced system complexity and design cost. LM5168FDDAR operates during input voltage dips as low as 6V, at nearly 100% duty cycle if needed, making the device an excellent choice for wide input supply range industrial and high cell count battery pack applications.

Specification Of LM5168FDDAR

Features Of LM5168FDDAR

• Functional Safety-Capable

• Documentation available to aid functional safety system design

• Designed for reliability in rugged applications

• Wide input voltage range of 6V to 120V absolute maximum

• Junction temperature range: –40°C to +150°C

• Fixed 3ms internal soft-start timer

• Peak and valley current-limit protection

• Input UVLO and thermal shutdown protection

• Designed for scalable industrial power supplies and battery packs

• Low minimum on and off times of 50ns

• Adjustable switching frequency up to 1MHz

• Diode emulation for high light-load efficiency

• Auto mode with low quiescent current (< 10µA)

• FPWM for Fly-Buck converter capability

• 3µA shutdown quiescent current

• Pin-to-pin compatible with LM5164-Q1, LM5163-Q1, and LM5013-Q1

• Similar pinout and functionality to LM5017 and LM34927.

• Integration reduces design size and cost

• COT mode control architecture

• Integrated 1.9Ω NFET buck switch

• Integrated 0.71Ω NFET synchronous rectifier

• 1.2V internal voltage reference

• No loop compensation components

• Internal VCC bias regulator and boot diode

• Open-drain power-good indicator

Applications Of LM5168FDDAR

• Communications – brick power module

• Industrial battery pack (≥ 10 S)

• Battery pack – e-bike, e-scooter, LEV
