PCM1862QDBTRQ1 audio front-end devices take a new approach to audio-function integration to ease compliance with European Ecodesign legislation, while enabling high-performance end products at reduced cost. The PCM1862QDBTRQ1 support single-supply operation at 3.3 V, and offer an integrated programable gain amplifier (PGA) in a small package; this configuration makes it feasible to implement smaller and smarter products at a reduced cost.
Specifications Of PCM1862QDBTRQ1
3 Converter
192 kS/s
24 bit
TSSOP-30
8 Input
3 V
3.6 V
- 40 C
+ 125 C
Moisture Sensitive:
Yes
Number of Channels:
2 Channel
Operating Supply Current:
18 mA
Pd - Power Dissipation:
80 mW
SNR - Signal to Noise Ratio:
103 dB
THD plus Noise:
- 93 dB
Unit Weight:
191 mg
Feature Of PCM1862QDBTRQ1
AEC-Q100 Qualified for Automotive Applications
Temperature Grade 1: –40°C ≤ TA ≤ +125°C
HBM ESD Classification Level 2
CDM ESD Classification Level C5
High SNR Performance:
110-dB SNR (PCM1861-Q1/63-Q1/65-Q1)
103-dB SNR (PCM1860-Q1/62-Q1/64-Q1)
ADC Sample Rate (fS) = 8 kHz to 192 kHz
Up To Four Independent ADC Channels Available
Single-Ended, 2.1-VRMS Full-Scale (FS) Input
Differential, 4.2-VRMS FS Input
Hardware (HW) Control: PCM1860-Q1/61-Q1
Software (SW) Control (I2C or SPI):
PCM1862-Q1/63-Q1/64-Q1/65-Q1
Support for Up To Four Digital Microphones
(SW-Controlled Devices)
Programmable Gain Amplifier (PGA):
Fixed Gain: 0 dB, 12 dB, 32 dB
(PCM1860-Q1/61-Q1)
SW-Controlled Gain: –12 dB to +32 dB
(PCM1862-Q1/63-Q1/64-Q1/65-Q1)
Integrated High-Performance Audio PLL
Single 3.3-V Power-Supply Operation
Power Dissipation at 3.3 V:
< 85 mW (PCM1860-Q1/61-Q1/62-Q1/63-Q1)
< 145 mW (PCM1864-Q1/65-Q1)
Energysense Audio Content Detector for Auto System Wakeup and Sleep
Master or Slave Audio Interface
Automatic PGA Clipping Suppression Control
PCB-Footprint Compatibility Across All Devices
Applications Of PCM1862QDBTRQ1
Automotive Head Units
External Car Amplifiers
Telematics Control Unit (TCU)
